The high-precision online KS-700 multi parameter analyzer detects pH, ORP, residual chlorine, turbidity, and temperature simultaneously. Wall-mounted and integrated, it offers parameter modification. The device supports DN15 threaded waterway interfaces, 4-20mA analog signals, RS485 (Modbus RTU), and optional DTU wireless transmission, and can link directly to cloud platforms. The equipment is modular, has high detection accuracy, and each instrument can be disassembled and maintained without impacting operation. Online water quality control in swimming pools, secondary water supply, water plants, cooling water, and other applications is common.
★★★★★
Multi Parameter Analyzer Features
Specifications
| Item | Specification |
|---|---|
| Measuring Parameters | pH, ORP, Free Chlorine, Turbidity, Temperature (Other parameters customizable on demand) |
| Power Supply | AC220V/DC24V optional, Max power 30W |
| Protection Grade | IP54, Wall-mounted installation |
| Environmental Requirements | Temperature 0~50℃, Relative humidity 10~90%RH |
| Waterway Interface | DN15 threaded connection (Other types customizable) |
| Overall Dimension | 800×600×250mm (H×W×D) |
| Built-in Meters | K042PRWM0800 + K050APPM0800 + K100MPPMA800 (Italy SEKO) |
| Digital Communication | K100 turbidity meter with standard RS485, Modbus RTU protocol |
Featured Applications
- Swimming Pool/Hot Spring: Swimming Pool, Water Park, Hot Spring Water Residual Chlorine pH、 Real time monitoring of turbidity, in compliance with hygiene operation standards;
- Industrial cooling: Monitoring the quality of industrial cooling water and circulating water to prevent water deterioration from affecting the normal operation of equipment and reduce equipment loss;
- Commercial water use: water quality monitoring of centralized water supply places such as hotels, shopping malls, hospitals, etc., to ensure daily water safety;
- Other scenarios: Daily online monitoring of water quality for landscape water, small-scale water plants, rural centralized water supply, and other water bodies.
Daily maintenance and precautions
Installation environment requirements
- Wall mounted installation is limited to indoor dry environments, avoiding direct sunlight, strong electromagnetic field interference, and contact with highly corrosive gases;
- The ambient temperature is maintained at 0-50 ℃, the relative humidity is 10-90% RH, and there is no risk of severe shaking or falling in the installation location;
- Reserve sufficient operating space for later equipment debugging, pipeline maintenance, and instrument disassembly, and the installation height should be convenient for instrument operation.
Periodic calibration
Long term use of electrodes and sensors may cause drift, and regular calibration is required to ensure detection accuracy. After calibration, records should be kept, and the calibration cycle reference is:
- Normal working conditions: industrial wastewater, swimming pool water and other complex water quality scenarios, calibrated every 15-30 days; In stable water quality scenarios such as surface water and tap water, calibration should be conducted every 30-60 days;
- Sensor calibration: It is recommended to calibrate pH/ORP every 1-3 months, turbidity every 3 months, clean every 6 months, and shorten the cycle appropriately in scenarios with poor water quality; All parameters support convenient on-site calibration and are easy to operate;
- Calibration method: Each instrument supports single point calibration/two-point calibration. Follow the instrument operating instructions and use standard calibration solution to complete the calibration. The calibration solution must be within its validity period and prepared in accordance with specifications;
- Special circumstances: In case of equipment shutdown and restart, replacement of sensors/electrodes, or significant drift in detection data, immediate recalibration is required.
Technical Support
Top 6 Industrial Gas Analyzers Manufacturers 2025
6 Best Industrial Gas Detector Manufacturers in the World
9 Best Portable Carbon Dioxide Detector 2025 – Complete Buying Guide
Top 7 portable combustion analyzer Tested
The KS-700 multi-parameter water quality monitoring cabinet has Italian SEKO equipment that let you do high-precision, modular, multi-parameter synchronous online monitoring. It may be used to control water quality in water supply, swimming pools, and industrial cooling since it can communicate data in multiple ways and be customized to meet your demands.
We offer professional water quality monitoring and safety solutions that work all the time, are easy to maintain, and can be changed to fit your needs.
