Industrial-grade water body fluoride ion sensor KSA-F-100.0 online. High-precision detection, Pt1000 automated temperature correction, and 5-8pH water sample environment are its features. IP68 high protection, RS-485 (Modbus/RTU) digital output, and 3/4NPT pipe thread immersion are available in the POM corrosion-resistant shell. A popular fluoride ion online detector in drinking water, industrial wastewater, and water environment monitoring, it is easy to use and maintain.
★★★★★
Parameters
| Item | Specification |
|---|---|
| Measuring Range | 0-100.00mg/L |
| Resolution | 0.01mg/L |
| Accuracy | ±10% or ±1mg/L, ±0.5℃ |
| Applicable pH Range | 5-8pH |
| Operating Temperature | 0-50℃ |
| Operating Pressure | ＜0.2MPa |
| Power Supply | 12-24VDC |
| Signal Output | RS-485(Modbus/RTU) |
| Temperature Compensation | Automatic Temperature Compensation (Pt1000) |
| Calibration Method | Two-point Calibration |
| Mounting Method | Immersion Installation, 3/4NPT Pipe Thread |
| Cable Length | 5m (Other lengths customizable) |
| Power Consumption | 0.2W@12V |
| Housing Material | POM |
| Protection Grade | IP68 |
Why choose KSA-F-100.0 Fluoride ion sensor?
- 0.01mg/L ultra-high resolution, measurement accuracy of ± 10% or ± 1mg/L, high detection accuracy
- Pt1000 automatic temperature compensation, working in a wide temperature range of 0-50 ℃, to counteract the interference of temperature on measurement
- POM corrosion-resistant shell, IP68 waterproof, working pressure<0.2MPa, suitable for complex water quality conditions
- RS-485 (Modbus/RTU) standard output, directly connected to PLC/DCS, supports remote data control
- 3/4NPT pipe thread immersion installation, 5-meter cable can be customized, suitable for multiple installation scenarios
Featured Applications
- Drinking water safety monitoring: online detection of fluoride ion concentration in waterworks and drinking water sources to control core water quality indicators of drinking water
- Industrial wastewater treatment: fluoride ion monitoring of production wastewater in the chemical, electroplating, and metallurgical industries, guiding process regulation to ensure standard discharge
- Natural water environment monitoring: Long term online monitoring of fluoride ions in rivers, lakes, groundwater and other water bodies to grasp changes in water environment quality
- Food and beverage processing: Fluorine ion detection of production process water and ingredient water meets the water quality standards for food and beverage production
Installation and wiring
Installation requirements
- 3/4NPT pipe thread immersion installation, ensuring that the measuring end is completely submerged in the water sample to be measured;
- Avoid strong water flow impact and dead corners of the tank to ensure sufficient contact between the water sample and the sensor;
- Only suitable for 5-8 pH water samples, water sample pretreatment is required if it exceeds the range.
Electrical wiring
- Standard 4-core twisted pair shielded wire, strictly check the wiring sequence before powering on to avoid equipment damage;
- Waterproof and anti-corrosion treatment should be carried out at the connection point, suitable for underwater, humid outdoor and other scenarios;
- Ensure stable power supply at 12-24VDC to prevent data drift caused by voltage fluctuations.
Maintenance and Calibration
Routine maintenance
- Regularly clean the measuring end with a soft bristled brush and distilled water to avoid scratching with hard objects, and use it after drying;
- Rinse the measuring end with distilled water before long-term discontinuation, dry it and store it in a dry and room temperature environment;
- Check the sealing of cable joints and reseal them promptly if they become loose or leak water.
Calibration operation
- Using the two-point calibration method, prepare two sets of fluoride ion standard solutions with low, medium, and high concentrations within the range of 0-1000mg/L;
- After rinsing the measuring end with distilled water, immerse it in two sets of standard solutions, and send calibration instructions to complete zero and slope calibration after the values stabilize;
- Calibrate once every 1-3 months under normal operating conditions, and shorten the calibration cycle for high pollution and high impurity water samples.
