A10PR: STREAMLINED pH/ORP CONTROLLER

The A10PR industrial pH/ORP online controller is a brand-new pH/ORP controller. This meter is highly intelligent and flexible,capable of simultaneously measuring pH, ORP, and temperature. It is widely used in municipal wastewater treatment plants, power plants, water supply systems, pharmaceuticals, chemicals, food processing, and other industries for continuous measurement of solution pH/ORP values.

★★★★★

  • Short delivery time
  • Better price
  • Customizable parameters

Features

  • Language diversity, Default standard Chinese interface, switchable to English interface.
  • Various temperature compensation options are available, including PT1000, NTC10K, and manual temperature compensation.
  • One 4-20mA output (optional 4-20mA output or RS-485 communication), corresponding to PH/ORP values ​​or temperature.
  • The two sets of relays can be switched freely between high and low points, and the hysteresis can be adjusted freely to avoid frequent switching of the relays.
  • Password management function to prevent accidental operation by non-professionals.
  • Menu prompts facilitate user operation.

Specifications

Measuring rangePH（0—14PH，0.0—14.0PH，0.00—14.00PH ）
ORP( -1999 — +1999 MV)
Accuracy±0.01 pH; ±1 mV
Resolution0.01 pH; 1 mV
Stability≤ 0.02 pH/24 hours; ≤ 3 mV/24 hours
Temperature Compensation0–100 °C Manual / Automatic (PT1000/NTC10K)
Signal Output4–20mA isolated protection output, independently corresponding to pH/ORP or temperature, with a load capacity up to 500Ω
Alarm OutputThree sets of high/low point alarms (3A/250 V AC) with freely assignable relay contacts
Power SupplyAC220V or DC24V
Power Consumption≤ 7W
Environmental ConditionsTemperature: 0–60 °C; Humidity ≤ 85% RH
Overall Dimensions96 × 96 × 128 mm (Height × Width × Depth)
Opening Size92 × 92 mm (height × width)

Featured Applications

Industrial circulating water

A10PR tracks cooling water PH, prevents pipe corrosion/scaling.

Light Chemical Industry

A10PR monitors mild chemical liquid PH, resists basic interference.

Electronics and Semiconductors:

Check the pH and ORP levels in ultrapure water to meet the strict standards for making chips.

Drinking water and food

Check how well the production water is disinfected to make sure food safety rules are followed.

Also flexible enough to be used in power plants, swimming pools, farming, and other places, meeting specific needs.

Working Principle of Online pH/ORP Controller

How an online pH/ORP controller works?

The pH/ORP electrode makes mild electrical impulses by touching the solution and changing the hydrogen ion concentration (pH) and oxidation-reduction potential (ORP). The temperature sensor also picks up the temperature of the space around it.

Signal Processing: The controller’s built-in chip amplifies and filters raw signals, applying temperature compensation algorithms (supporting automatic PT1000/NTC10K recognition) to correct temperature effects on measurements.

Data Display and Calculation: Processed data displays real-time pH/ORP values and temperature on the screen while automatically comparing against preset alarm thresholds.

Output Control: If data exceeds thresholds, two sets of relays activate peripheral devices such as dosing pumps and alarms. Isolated 4-20mA outputs or communication interfaces transmit data to PLCs/monitoring platforms, completing the “monitoring-control-traceability” closed-loop system.

Technical Support

1. Clean the electrode after preheating; 2. Immerse in 4.00 pH standard solution, press confirm once the mV value stabilizes; 3. After rinsing, immerse in 6.86 pH standard solution, press confirm once stabilized.

High-salt mode enhances anti-polarization, with ORP error ≤±3mV and strong adaptability.

The A10PR achieves continuous monitoring through a four-step process: electrode collection, signal processing, intelligent computation, and data output. When compatible electrodes (such as the GRT1320) come into contact with the solution, they convert pH/ORP ion signals and temperature signals into electrical signals. The controller’s built-in high-precision chip filters, amplifies, and performs temperature compensation calculations on these signals. Combined with scene mode optimization algorithms, it ultimately outputs precise data and triggers abnormal alarms.

Top 6 Industrial Gas Analyzers Manufacturers 2025

Posted on
Introduction to Industrial Gas Analyzers Industrial gas analyzers are critical instruments used across numerous sectors to measure and monitor the composition of gas mixtures in various processes. These sophisticated devices…

6 Best Industrial Gas Detector Manufacturers in the World

Posted on
With industrial safety standards becoming more stringent each year, organizations worldwide are investing in high-precision gas detection technologies. Choosing the Best industrial gas detector manufacturers ensures operational safety, regulatory compliance,…

Top 7 portable combustion analyzer Tested

Posted on
Introduction to Portable Combustion Analyzers A portable combustion analyzer is an essential diagnostic tool for technicians, engineers, and facility managers working with combustion systems. These sophisticated instruments measure and analyze…

Choose A10PR for more precise and hassle-free water quality monitoring

From complex municipal wastewater conditions to the extreme precision required for semiconductor ultrapure water, the A10PR redefines industrial-grade pH/ORP monitoring with its three core advantages: high accuracy, ease of operation, and strong adaptability. 0.01pH resolution captures minute fluctuations, 5 scene modes adapt with a single button press, 3-step calibration makes it easy for beginners to master, 100,000 data storage slots + compliant export meet all scenario needs, IP65 protection ensures stable operation in high-temperature, humid, and electromagnetic interference environments, reducing failure rates by 40%.

Trusted by over 500 enterprises, its value is proven: wastewater treatment compliance rates increased by 8%, lab reporting efficiency boosted by 92%, and maintenance teams doubled their device management capacity! Whether ensuring production compliance or reducing operational costs, the A10PR is your intelligent water quality monitoring steward.
